Large A1 Four-Color Packaging offset printing press

The press utilizes high-precision bearings from well-known brands, adopts a design of 7 o'clock cylinder arrangement and a double-diameter impression cylinder and transfer cylinders, which greatly improves print quality and enables it to handle a wider range of substrates, especially those of thicker stock. It can process paper thicknesses ranging from 0.04mm thin paper to 0.6mm thick cardboard. Furthermore, it is equipped with a microcomputer control system and a touch screen with an intuitive user interface, allowing for smart programming of settings and parameters as well as real-time monitoring and diagnosis of the printing process. The Large A1 Four-Color Packaging offset printing press has been proven to be a cost-effective and high-performance printing machine, earning a great reputation in both commercial and packaging printing for either long or short production runs.

Technical Parameters

● Plate register remote control device. Automatic plate micro adjustment in vertical, lateral and diagonal, quick and convenient for image setting
● Micro computer control, touch screen to fully control and monitor all functions during printing
● Alcohol dampening system, improve color transfer, insure the printing quality.
● Unit type separated frame & basement, convenient for unit matching. exchangeable and cost reduced
● Remote ink console, insures the quick response when color is going to be changed
● Auto blanket washing and auto ink roller cleaning device, shorten the washing and color changing time, improve the working efficiency and reduce thelabor work

● Vacuum suction table. Saving the Pager changing time by only easily adjusting the brush and rotation wheel,the paper feeding tape insures paper conveying safely and stably.

● Water and ink fountain roller is controlled by program and drived by motor,keeping the same timing with printing speed,and providing the stable ink volume and dampening solution
● Cylinder ON/OFF controlled pneumatically, take good use of machine space,improved the stability,and reduced the vibration and noise
● Semi-automatic plate loader,make the plate loading more quicker and exactly,reduce the plate loading time.

● Heavy duty mechanism structure. Cast iron pedestal, frame, cylinder etc. have the good intension and tenacity, ensuring high stability and good printing impression.
● High precision import bearing, ensuring printing quality even in high speed rotation.
● Advanced structure and functions,SEvEN o'clock cylinder arrangement,double diameter impression and transferring cylinder design,more suitable forthicker paper printing
