18-inch (457mm) Two-Color Computerized Forms Printing Press
This 18-inch (457mm) Two-Color Computerized Forms Printing Press for continuous feed computer paper of 18 inches of maximum width, designed and manufactured by Weihai Printing Machinery Co., Ltd., is mainly for printing multi-part forms, especially those of small quantity but on large variety of continuous computer papers, especially performing two-color overprinting on tabular forms of different sizes ranging from 4 inches x 7 inches to 18 inches x 14 inches, notably overprint on multi-variety forms with skip-print capability.
The 18-inch (457mm) Two-Color Computerized Forms Printing Press is two-color computer form printing machine, manufactured by Weihai Printing Machinery Co., Ltd., is a specialized printing equipment for printing multi-part forms, continuous forms, and other documents. It has been proven high efficiency and low cost for high-volume production of standardized two-color forms. It is ideal for continuously printing of small batches of various computer forms, and it can overprint different form sizes ranging from 4 inches x 7 inches to 18 inches x 14 inches in two colors. It features a skip printing function, allowing it to print multiple types of forms and overprint various computer paper forms.
Product Features
① Continuous paper feeding facilitates printing module adjustment.
② High-precision paper registration.
③ Two color printing on a single paper pass.
④ Computerized tabular forms printing.
⑤ Advanced digital servo motor drive.
⑥ Advanced touchscreen display system.
Technical Parameters
| Paper Width (inches) | 4”-18” | Skip Printing Range(sheets) | 0-999 |
| Paper Length (inches) | 7“-14”(以1/6"or 1/8"incrementaladjustment) | Dampening System | Water Sleeves |
| Paper Thickness(mm) | 0.06-0.2 | Rollers Per Unit | 10 Ink Roller4 Water Rollers |
| Max.Printing Area(W*L)(mm) | 460x355 | Image Longitudinal Adjustment(mm) | ±100 from both ends |
| Printing Speed(sheet/hour) | 3000-6000 | Image Longitudinal Fine Adjustment(mm) | ±1at the 2nd Unit |
| Plate Size(mm) | 464x478 | Image Transversal Fine Adjustment(mm) | ±1 at the 2nd Unit |
| Plate Thickness(mm) | 0.15 | Sheet Longitudinal Fine Adjustment(mm) | 0.05 Incremental |
| Plate Type | Plate Straight Edge Clamp | Sheet Traversal Fine Adjustment(mm) | ±2 |
| Blanket Size(mm) | 464×476x1.9 | Power Supply | 220V 50Hz |
| Cylinder Packing(mm) | 464x458x0.6 | Motor Consumption | Main Motor 750wPaper Driven Motor 400w |
| Feeder Capability(mm) | 300 | Dimension(LxWxH)(mm) | 1580x980x1400 |
| Paper Collection | Swing cage reversing distribution | Weight(kg) | 700 |
| Paper Collector Capacity(mm) | 340 |
|
|
